Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways

Gnee Steel (tianjin) Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways

  • 1
  • 2
  • 3

Brand Name : GNEE

Certification : SGS

Place of Origin : China

Price : Negotiable

Payment Terms : Negotiable

Delivery Time : 5-9 working days

Packaging Details : Sea-worthy packing, ie wooden or steel tray with steel strip,etc

Contact Now

Steel bar grating, known for its high strength and robust structure, is manufactured from carbon steel, aluminum, or stainless steel. Depending on the production method, steel grating can be categorized into four types: welded bar grating, press-locked grating, swage-locked grating, and riveted grating. Based on surface design, it is available in both smooth and serrated options. With a wide range of styles and sizes, steel grating serves versatile applications in everyday life, including stair treads, walkways, platforms, flooring, trench covers, wheeled equipment, security screens, and heavy-duty constructions.
Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways
Welded bar grating
Press Lock Grating
Swage Locked Grating
Welded bar grating is also called metal open bar grating. Welded bar grating, also known as metal open bar grating, comes in two types: smooth and serrated. Smooth, or plain steel bar grating, is more popular, but serrated grating offers better skid resistance.
Made from low carbon steel, stainless steel, or aluminum, is created by bonding slotted bars under hydraulic pressure. It's strong, durable, and widely used in industrial and commercial applications like stair treads, platforms, walkways, and covers. Serrated surfaces enhance anti-slip properties.
Swage locked grating, mainly made of aluminum or stainless steel bars, is formed by inserting cross bars into pre-punched bearing bars and locking them under hydraulic pressure. It comes in three bearing bar types: rectangular, T, and I bars, with I bars being lighter and more affordable.

Material
Carbon Steel, Stainless Steel, Aluminum
Surface treatment
Hot dipped galvanized, Spray painting, Polished and powder coated
Bearing bar type
Plain(Flat) bar, Serrated bar, I-bar, etc.
Common specification
Bearing bar pitch (mm)
Cross bar pitch (mm)
Bearing bar size
(WSG_Height×Thickness_Bearing bar pitch_Cross bar pitch)
30
100
WSG_203/253/323/403/205/325/405/455/505/555_30_100
50
WSG_203/253/323/403/205/325/405/455/505/555_30_50
40
100
WSG_203/253/323/403/205/325/405/455/505/555_40_100
50
WSG_203/253/323/403/205/325/405/455/505/555_40_50
60
50
WSG_203/253/323/403/205/325/405/455/505/555_60_50
If you have any questions regarding the dimensions or specific specifications, please feel free to contact us immediately.

Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways

Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways

Heavy-Duty ASTM A36 Carbon Steel Galvanized Bar Grating Serrated Welded Floor Grate for Walkways
